Hameg HM5014-2 Service Manual

11
Subject to change without notice
1. Basics
TG OUTPUT
Insertion unit
(M3)
HM5014-2
NRVS
M2
Figure 1.3.3: Measurement SETUP 3
Item Type of Accessories, Requirements Purpose
A1 “Screwdriver” with ceramic blade for adjustment (older
version), Murata No. KMTZ16F
Adjustment of TCXO (older version)
A2 “Screwdriver” with ceramic blade for adjustment (newer
version), Murata No. KMTZ11V
Adjustment of TCXO (newer version)
A3 Jaw wrench with wrench size 8 mm (max 3 mm thick) Removing / mounting SMA nuts, semi-rigid cables
A4 Screwdriver for crosshead screw Removing / mounting screws
A5 Screwdriver for adjustment purposes Adjustment of various potentiometers
A6 Pair of long-nosed pliers Removing or mounting connectors
A7 Serial Interface IF unit is equipped with interface other than serial
A8 Probe power test cable Measuring probe supply
A9 Jaw wrench with wrench size 5.5 mm Removing / Mounting hex nuts
Measurement setup 3
This measurement setup is used to determine the power of
signals over the entire frequency range of the HM5014-2. The
NRVS [M2] is always used with the insertion unit [M3].
Table 1-2

Hameg HM5014-2 Specifications
