6. Spare Parts Handling
This chapter provides information on the ordering of spare
parts and contains the spare parts list.
6.1 Shipping of Instrument
or Modules
Please contact your HAMEG support center or the HAMEG spa-
re parts express service if you need service or repair of your
equipment or to order spare parts.
We require the following information in order to answer your
inquiry fast and correctly and to decide whether the warranty
still applies for your instrument:
– Instrument model
– Stock No.
– Serial Number
– Firmware version
– Detailed error description in case of repair
– Contact partner for checkbacks
When shipping the instrument, be careful to provide for suffi -
cient mechanical and antistatic protection. Repack the instru-
ment as it was originally packed when transporting or ship-
ping. The two protective foam plastic parts prevent the control
elements and connectors from being damaged.
6.2 Ordering Spare Parts
The stock numbers are necessary for ordering replacement
parts and modules.
6.3 Spare Parts List
Spare Part Stock Number
IFA Module
29-2000-0015
RFI Module
29-2000-0013
TG Module
29-2000-0017
RAT Module
29-2000-0005
XYZ Module
29-2000-0007
CPU Board
29-2000-0016
PS Module
29-2000-0002
KEY Module
29-2000-0012
CRT Module
29-2000-0029
Serial Interface (IF Module)
29-2000-0018
Front cover
29-2000-0019
Rear cover
29-1000-0010
Knob Set
29-2000-0020
Plug cable cpl.
29-2000-0044
Screen fi lter pane
29-1000-0012
Coaxial pipes
29-2000-0042
Flat cable Set
29-2000-0043
Casing
29-1000-0064
Handle
29-1000-0068
6.4 Hameg Tool Kit HM5014-2
For module replacement some special tools are needed. The-
se tools are indicated in table 1-2, item A1, A2, A7 and A8. All
these items belong to the Hameg tool kit HM5014-2 and can be
ordered under the stock number 29-2000-0045.
