INTERFACE AND FUNCTIONS
USB
LINE IN LINE OUT
FACT
DC IN
21V 5A
LAN
WIFI
BT
L R
SPEAKERS
RESET
3
8
7
2
4 9 5
6
1
① WiFi Antenna: Used for Wi-Fi connecon
② Factory Reset: Used to reset the device if you have a
problem with your Wi-Fi connecon
③ Network Connecon: RJ45 used to connect to a
wired Ethernet network
④ Line Input: Analog input used to connect audio devices
via an RCA cable
⑤ USB Port: Used to connect local storage devices
⑥ Speaker Terminals: Phoenix speaker terminal used to
connect speakers
⑦ Power Input: DC power input used to connect the power
adaptor
⑧ Bluetooth Antenna: Used to pair with mobile devices
using a popular wireless service
⑨ Pre Out: Used to provide analog signal to amplier
Rear Panel
To Next Page
