Hamilton WSA50 - Wiring Diagrams

5
WIRING DIAGRAMS
1. Plug Socket
2. For In-Ceiling Installaon -
Connect using a switched fused spur.
Power the amplier with the power adapter included in the
accessories.
POWER SUPPLY
POWER SUPPLY
SWITCHED FUSED SPUR 3AMP
We recommended you have access to the switched fused
spur.
21V DC IN
21V DC IN
