Modify the center area size
Commonly used center area size can be set by scanning the following setting code:
Center area -20%
Center area -40%
Center area -60%
When the size of the commonly used central area does not meet the needs, the user can also customize
the configuration by scanning the "edit center area size" setting code.
Modify the center area size
Example:modify the 50% center area size
1. Check the character table to get "50" four characters hexadecimal value: "32"
2. Check whether the setting code is on. If it is not on, please scan the setting code "on" (see section 1.5.2)
3. Scan "Modify center area size" setting code
4. Scan the data setting code "3", "2" (see appendix E)
5. Scan "save" setting code (see Appendix F)
