Hammer Q.Vadis 10.0 User Manual

10. Teileliste / Parts list
24
Position Bezeichnung Description Abmessung/Dimension Menge/Quantity
5163 -
- 1 Vorderer Rahmen Treadmill Base 1
- 2 Steigungsmotor Incline motor 1
- 3 Fixier Stift oben Upper fixing pin 1
- 4 Fixier Stift unten Lower fixing pin 1
- 5 Steigungsfuß Lifting leg 1
- 6 Schraube Screw M10x50 2
- 7 Stütze links/rechts Upright post left/right 2
- 8 Zylinder Hydraulic rod 1
- 9 Schraube Screw M8x45 1
- 10 Schraube Screw M8x30 1
- 11 Unterer Rahmen Treadmill underframe 1
- 12 Abdeckung hinten Rear support cover 2
- 13 Fuß hinten Bottom foot 2
- 14 Dämpfer Damping block 6
- 15 Motor dämpfer Motor damping pad 1
- 16 Motor Motor 1
- 17 Schraube Screw M8x25 4
- 18 Schraube Screw M8x65 1
- 19 Platine Power supplie board 1
- 20 An/ Aus Schalter Power Switch 1
- 21 Buchse Power cord socket 1
- 22 Sicherung Fuse 1
- 23 Filter Wave filter 1
- 24 Kondensator Reactor 1
- 25 Touch screen Touch screen 1
- 26 Schraube Screw M8x40 2
- 27 Display Display 1
- 28* Handgriff Handrail 2
- 29 Schraube Screw M8x16 4
- 30* Riemen Belt 1
- 31 Rolle vorn Front roller 1
- 32 Schraube Screw M6x60 1
- 33* Laufdeck Running board 1
- 34 Schraube Screw M8x60 8
- 35 Schraube Screw M8x60 2
- 36 Rolle hinten Rear roller 1
- 37 Schraube Screw M8x75 2
- 38* Laufgurt Running belt 1
- 39 Abdeckung hinten Post adjuster 2
- 40 Seitenschiene Sidebar 2
- 41 Obere Plastikabdeckung Top stripe 2
- 42 Halterung Edge block 2
- 43 Disk Disk 2
- 44 Untere Motoren Abdeckung Lower motor cover 1
- 45 Abdeckung Standfuß Foot protection 2
- 46 Motor Abdeckung Motor cover 1
- 47 Vordere Abdeckung Front cover 1
- 48 Halterung Trinkflasche Bottle holder 1
- 49 Schraube Screw M5x16 2
- 50 Untere Display Abdeckung Cover under monitor 1
- 51 Schraube Screw M4x8 2
- 52 Schraube Selbstschneident Screw self tapping M4x12 16
- 53 Rahmen Bildschirm Monitor frame 1
- 54 Abdeckung Mutter Lock Cap M10 2
- 55 Platine Circuit board 1
- 56 Not Aus Platine Emergency circuit board 1
- 57 Schrauben selbstschneident Self tapping screw M3x8 10
- 58 Abdeckung Bildschirm oben Monitor top cover 1
- 59 Handpuls Heart pulse electrode 2
- 60 Bildschirm touch screen 1
- 61 Bildschirm Abdeckung Touch screen fron cover 1
- 62 LCD screen LCD screen 1
- 63 Bilschirm Halterung Display block 4
- 64 Schraube Screw 3x8 14
- 65 Platte inner support plate 1
- 66 Muffe Support block 4
- 68 Schraube Screw M3 4
- 69 MP3 Platine MP3 board 1
- 70 Abdeckung hinten Back cover 1
