4V LITHIUM RECHARGEABLE SCREWDRIVER 17
10. Wire Stripping
The tool is fitted with a wire stripper
for stripping 0.5~2.5mm
2
wire sizes.
a. Select the opening in the stripping
lever that matches the wire size.
b. Insert the wire and depress the
wire stripper lever to clamp the
wire stripper around the wire.
c. While holding the wire rmly,
slowly swing the tool around the
wire to cut the insulation
d. Pull the tool back to strip the wire
insulation.
11. Wir e Bending
The wire bending hole is located on
the bit holder.
To bend a wire, insert it into the wire
bending hole, hold the wire with one
hand and move the tool to bend the
wire as needed.
10
WIRE STRIPPER
LEVER
OPENING
11
WIRE
