Assembly (continued)
10
Attaching the locking knob to the lower umbrella pole
Attach the locking knob (D) to the lower umbrella pole (C) using the M5x8 bolts (BB) and hex wrench (DD). Make sure the
locking knob (D) is placed as shown in figure 1 before attaching.
NOTE: When inserting the locking knob (D) into the hole,
make sure the two points of the locking knob fit into
the two slots on the umbrella pole as shown below.
1
2
C
BB
DD
D
gure 1
gure 2
