HAMPTON BAY ELSMERE - Pre-installation; Planning the Installation; Tools Required; Hardware Included

Pre
-installation
PLANNING THE INSTALLATION
Read all instructions before assembly and installation. Before starting installation of the fixture or removal of a previous
fixture, disconnect the power by turning off the circuit breaker or by removing the fuse at the fuse box. To avoid
damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard.
NOTE: Keep your receipt and these instructions
for Proof of Purchase.
TOOLS REQUIRED
HARDWARE INCLUDED
NOTE: Hardware not shown to actual size.
3
Part
Description
Quantity
AA
Fixture Screw
4
BB
Mounting Screw
2
CC
Wire Nut
3
DD
Cage Screw
2
EE
Mounting Plate
1
Ladder
Safety
Goggles
Electrical
Tape
(1)
Incandescent
60 W Bulb or
CFL or LED
Equivalent
Phillips
Screwdriver
Wire
Cutter
Wire
Stripper
Flathead
Screwdriver
Pliers
