THANK YOU

We appreciate the trust and condence you have placed in Hampton Bay through the purchase of this doorbell. We

strive to continually create quality products designed to enhance your home. Visit us online to see our full line of

products available for your home improvement needs. Thank you for choosing Hampton Bay!

USE AND CARE GUIDE

WIRELESS OR WIRED DOORBELL

Questions, problems, missing parts?

Before returning to the store, call Hampton Bay Customer Service

8 a.m. - 5 p.m., CST, Monday - Friday

1-844-760-3644

HAMPTONBAY.COM

Illustrations may vary from actual unit.

Item #1001407776

1001407811

1001411352

1001407817

Model #HB-7612-02

HB-7614-02

HB-7615-02

HB-7616-02

Item #1001407818

1001407820

1001407821

1001407823

Model #HB-7617-02

HB-7618-02

HB-7621-02

HB-7671-02

Questions and Answers

J
Jeffrey MoralesOct 31, 2025
How to troubleshoot HAMPTON BAY HB-7614-02 Accessories doorbell that does not sound?
- H
  hgarciaOct 31, 2025
  To troubleshoot why your HAMPTON BAY Accessories doorbell isn't sounding, first, test the transformer voltage output using a voltmeter set to A/C voltage. It should read between 18-22 volts A/C when the doorbell is not in use. If it's below 18 volts, replace the transformer. If the transformer is fine, remove the push button from the door frame, disconnect the wires, and touch the bare wires together. If the doorbell rings, the push button is defective and needs replacement. As an additional check, disconnect the wire from the 'TRANS' terminal. While someone presses the front door push button, quickly touch the 'TRANS' wire to the 'FRONT' terminal. A small spark indicates the button, wiring, and transformer are working. Repeat for the 'REAR' terminal and button. If the wiring is okay, then...
A
Angela SmithNov 15, 2025
What to do if HAMPTON BAY HB-7614-02 doorbell doesn't play the entire tune?
- G
  Grace FreemanNov 15, 2025
  If your HAMPTON BAY Accessories doorbell sounds but doesn't play the entire tune, or the 'TUNE' button isn't working, it might be due to the push button diode. Ensure the diode is securely attached to the main push button. If a diode is installed on more than one push button, the doorbell may not function correctly. If the push button has a pre-installed diode, do not install an additional one. If the musical tune still doesn't sound completely, replace the diode (Type 1N4001-50V- 1A, available at a local electrical component supplier). If the diode is correctly connected to the 'FRONT' door push button and the doorbell plays the entire tune, the doorbell might not be receiving enough power. Test the transformer voltage output with a voltmeter set to A/C voltage. The voltage should be betw...
