Cabinet Assembly (Continued)
8
Attaching 2 cabinets together
 Install 8 metal plates (GG) into the underside of the TOP CABINET and secure with 2 screws (BB) for each metal plate (DO NOT
TIGHTEN THE SCREWS AT THIS STEP)
IMPORTANT: To lift the Pantry up, at least 2 people are required.
NOTE: Metal brackets GG and screws BB are
packed inside the BASE CABINET package
 Install the top into the base so that the dowels and the metal plates on the top are aligned with the base.
 Secure with 2 crews (BB) for each metal plate at the base then tighten all the screws both top and base.
BB
GG
TOP CABINET
