a. Blade attachment hardware
(9 screws)
b. Mounting & Electrical Hardware
(1 hanger pin, 1 locking pin, 3 plastic
wire connectors, 1 rubber gasket)
c. Blade Balancing Kit
d. Blade Bracket Hardware
(6 screws and lockwashers)
6. Blades Brackets (3)
7. Blades (3)
8. Lower Housing
9. Glass
10. Transmitter (Hand Unit)
1. Mounting Plate (inside Canopy)
2. Downrod and Ball Assembly
3. Canopy
4. Decorative Motor Collar Cover
5. Fan Motor Assembly
2. Unpacking Your Fan
IMPORTANT: THIS PRODUCT AND/OR COMPONENTS ARE COVERED
BY ONE OR MORE OF THE FOLLOWING U.S. PATENTS: 5,947,436;
5,988,580; 5,971,573; 6,010,306; 6,039,541; 6,046,416 AND OTHER
PATENTS PENDING.
Unpack your fan and check the contents. You should have the following items:
1
6
2
3
4
5
7
8
9
10
a
b
c
d
REMOVE RUBBER PACKING MOUNTS IN THE
FAN MOTOR ASSEMBLY AND DISCARD BEFORE
INSTALLATION.
To Next Page
