HAMPTON BAY SW20006 ORB - Installing the Light Kit; Light Kit Plate and Bulbs

10
J
L
PP
LL
Attaching the light kit plate to
the mounting plate
Remove one of the screws (LL) from the mounting
plate (I) and loosen the other two screws (LL), but
do not remove.
While holding the light kit plate (J) under your fan,
firmly snap the wire connection
plugs (PP) together.
Place the key holes
from the light kit plate (J) over the
two screws (LL) previously loosened from the
mounting plate (I).Turn the light kit plate (J) until it
locks at the narrow section of the key holes.
Secure by tightening the two screws (LL) previously
loosened and the one screw (LL) previously removed.
Install the two 9W LED bulbs (L) into the
sockets (QQ).
J
QQ
Installing the LED bulbs
