10
Operating Your Transmitter
Figure 17
Figure 16
ON ECE
1234
ON
D
Your DC brushless motor is equipped with a automatically learned type remote control. Restore power
to ceiling fan and test the transmitter as below for proper operation:
Install one 23A/12V battery (included). To prevent damage to transmitter, remove the battery if not
used for long periods of time. (Fig. 16)
A. I, II, III, IV, V and VI button:
These six buttons are used to set the fan speed as follows:
1 = minimum speed
2 = low speed
3 = medium low speed
4 = medium speed
5 = medium high speed
6 = high speed
B. button:
This button turns the fan off.
C. Reverse button:
This button is to control fan direction
D. Light button
This button is to control light. Switch the “D” and “ON” dip switch on the back of transmitter to decide
the light in “ON/OFF” or “Dimmable” condition.
1
2
3
4
6
5
