HAMPTON BAY AG524-WH - User Manual

20 pages

Save Page as PDF

To Next Page

USE AND CARE GUIDE

GLENDALE 52 IN. CEILING FAN

THANK YOU

Item #227 462

Model #

AG524-WH

1-855-HD-HAMPTON

HAMPTONBAY.COM

Questions, problems, missing parts? Before returning to the store,

8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST Saturday

call Hampton Bay Customer Service

xxx xxx

Questions and Answers

E
emurphyAug 5, 2025
How to fix a wobbling HAMPTON BAY Fan?
- C
  Christina SalinasAug 5, 2025
  To fix a wobbling HAMPTON BAY Fan, start by verifying that all blades and blade bracket screws are tightened securely. After ensuring the fan is properly installed, let it run for 10 minutes to self-adjust. Check blade level by measuring the distance from each blade to a fixed point on the ceiling; deviations should be within 1/8 inch. If the wobble persists and deviations are minimal, contact Customer Service (1-855-HD-HAMPTON) to order a complimentary Blade Balancing Kit. If any deviation exceeds 1/8 inch, contact Customer Service (1-855-HD-HAMPTON) to order complimentary replacements of your brackets.
R
raymond34Aug 19, 2025
What to do if my HAMPTON BAY AG524-WH Fan wobbles?
- R
  Raymond PowellAug 19, 2025
  If your HAMPTON BAY Fan wobbles, verify that all blades and blade bracket screws are secure. After proper installation, run the fan for 10 minutes to allow it to self-adjust. Also, check the blade level: select a point on the ceiling above the tip of one blade, then measure from the center of each blade to that point. Measurement deviations should be within 1/8 inch.

Summary

Safety Information

Warranty

Pre-Installation

SPECIFICATIONS

Details fan size, speed, electrical ratings, and dimensions.

TOOLS REQUIRED

Lists necessary tools for installation, including screwdrivers and ladder.

HARDWARE INCLUDED

Identifies and quantifies all included screws, nuts, and fasteners.

PACKAGE CONTENTS

Lists all components included in the fan package with quantities.

DUAL MOUNTING INSTRUCTIONS

Explains two hanging methods: standard and close-to-ceiling.

Installation

MOUNTING OPTIONS

Details how to mount the fan to the electrical box or ceiling structure.

Assembly - Standard Ceiling Mounting

Assembly - Close-to-Ceiling Mounting

Assembly - Hanging the Fan

Attaching the fan to the electrical box

Instructions for securing the mounting bracket to the outlet box.

Hanging instructions for standard mounting

Steps for hanging the fan using the standard downrod method.

Hanging instructions for close-to-ceiling mounting

Steps for hanging the fan using the close-to-ceiling method.

Assembly - Hanging the Fan: Electrical Connections

Making the electrical connections

Guides on connecting fan wires to household electrical wiring.

Assembly - Hanging the Fan: Canopy Attachment

Standard ceiling mounting

Final canopy attachment for standard mounting.

Close-to-ceiling mounting

Final canopy attachment for close-to-ceiling mounting.

Assembly - Attaching the Fan Blades

Removing the rubber packing mounts

Instructions to remove protective mounts before blade attachment.

Attaching the blades to the blade arms

Steps for securing fan blades to their respective arms.

Fastening the blade assemblies to the motor

How to attach the blade arms to the fan motor housing.

Assembly - Installing the Light Kit

Attaching the light kit to the switch housing

Connecting the light kit wiring and mounting it to the fan.

Mounting the glass shades and installing the light bulbs

Installing glass shades and LED bulbs into the light kit.

Operation

PULL CHAIN OPERATING INSTRUCTIONS

How to use pull chains for fan speed and light control.

REVERSE SWITCH OPERATING INSTRUCTIONS

How to use the reverse switch for airflow direction.

Care and Cleaning

Troubleshooting

The fan wobbles.

Procedure to diagnose and fix fan wobble issues.

Service Parts

HAMPTON BAY AG524-WH Specifications

General

Type	Ceiling Fan
Color	White
Blade Span	52 inches
Motor Type	AC Motor
Number of Blades	5
Control Type	Pull Chain
Blade Color	White
Fan Diameter (in.)	52
Fixture Color/Finish	White
Indoor/Outdoor	Indoor
Light Type	LED
Blade Pitch	12 degrees
