Hamron 012452 - Installation; Positioning the Camera

EN
26
FIG. 3
2. Place the camera. Screw the number
plate holder and mounting plate in place
with the screws.
FIG. 4
3. Replace the number plate in the holder.
FIG. 5
4. Route the power cable from the camera
to a suitable connection point in the
reversing light circuit. Get professional
help with the installation if necessary.
5. Some vehicles already have holes
through which the cable can be routed,
for example the hole for the cable to the
number plate lighting. Otherwise drill
a hole in the bodywork near the cable
inlet in the camera housing. Remove the
camera from the vehicle after choosing
the place for the cable inlet in the
bodywork. Skip the next two steps if an
existing hole is used.
6. Before drilling the inlet hole in the
bodywork, carefully check what there is
on the inside of the bodywork. Take the
necessary steps to avoid damaging any
vehicle components, electrical equipment
or parts of the fuel system. Remove the
number plate and camera before drilling
the hole.
7. Drill and deburr the hole, insert the
supplied grommet and route the cable for
the camera through the grommet in to
the vehicle. The grommet should always
be used, otherwise the sheet metal can
damage the cable.
8. Localise the reversing lights on the
vehicle. Turn the ignition key to garage
mode, apply the parking brake and put
the vehicle in reverse to switch on the
reversing lights. Go behind the vehicle and
check where the reversing lights (white)
are. To localise the +12 V/+24 V wires to
the reversing lights you need access to the
1. Monitor and holder
2. Power cable for monitor
3. Camera and mounting plate
4. Ferrite core for camera cable
5. Assembly parts
FIG. 1
INSTALLATION
NOTE:
• This product is universal. The instructions
are therefore a guide and do not apply to
all vehicles. For specic questions
concerning vehicle, contact the vehicle
manufacturer.
• Incorrect installation can invalidate the
warranty.
• If necessary get an automotive
electrician or other qualied person to
connect to the vehicle’s electrical system.
• Never route the cable on the outside of
the vehicle.
INSTALLATION
Positioning the camera
The camera can be installed on the back of the
vehicle in several dierent ways. In most cases
it is best to install it near the number plate.
Adjust the angle of the camera so that the
camera view is unobstructed.
FIG. 2
On some vehicles it is not advisable or
impossible to mount the camera near the
number place and another more suitable place
needs to be chosen.
1. Remove the rear number plate, holder
and screws from the vehicle.
