EN
51
CONNECTION
NOTE:
• The minimum hose dimension is 1/2” (13 mm).
• The hose must be reinforced.
• The incoming water ow must be at least the same as the maximum ow for the high-pressure washer.
1. Place the high-pressure washer on a level and stable surface.
2. Fit the spray nozzle in the spray gun or terrace washer and twist to lock in place (diagram 1).
3. Connect the spray gun to the high-pressure hose (diagram 2).
4. Connect the high-pressure hose to the outlet on the high-pressure washer.
5. Connect the female connector (diagram 3) on the water hose to the inlet on the high-
pressure washer.
1
2
3
