USE
INTENDED USE
• The high-pressure washer with the spray gun is intended to be used to clean vehicles, machines
and buildings etc.
• The high-pressure washer with the terrace washer is intended to be used to clean terrace oors etc.
• The high-pressure washer is only intended for household use.
ADJUSTING THE SPRAY GUN
NOTE: Do not adjust the nozzle when the trigger is pressed.
Spray pattern
1. Twist the front of the nozzle to make the water jet narrower or wider (diagram 4).
ADJUSTING THE SPRAY HEAD
High-pressure mode
NOTE: Detergent can only be used in low-pressure mode.
The nozzle must be in the IN position for the high-pressure jet.
1. Turn the nozzle clockwise as far as it goes until there is no gap between the nozzle and and
the base to activate high-pressure mode/IN position (diagram 5).
4
Wide spray pattern
Narrow spray pattern
5
IN- position
