Operation p. 12
USER GUIDE CEILING MOTOR
6. Operation
6.1. The electric handcontrol for 2815 and 2810 L
The electric handcontrol (J/K), connected to the Ceiling Motor with the spiral cable and connector, has either two
(2815) or four buttons (2815 L), depending on the motor version.
UP and DOWN, LEFT and RIGHT are marked with the appropriate arrows.
LIFTING MOTOR LATERAL MOTOR
UP DOWN LEFT RIGHT
CAUTION!
do not move the ceiling motor by PUlling the handcontrol.
J K
