USER GUIDE CEILING MOTOR
10. Technical specifications
A
B
C
Length (A) 16.14 inch / 41.00 cm
Width 13.78 inch / 35.00 cm
Height (B) 7.48 inch / 21.00 cm
Height until swivel hook (C) 9.84 inch / 25.00 cm
Standard length of motor band 78.74 inch / 200.00 cm
Height of the rail depending on type of rail
Maximum load 440.92 Lbs / 200.00 kg
Maximum weight lift + accessories 507.06 Lbs / 230.00 kg
Tension 24V DC
Power 10A
Weight 2815 and 2805 IR 40.12 Lbs / 18.2 kg
Weight 2810 L and 2815 L IR 46.30 Lbs / 21.00 kg
Leadbatteries, sealed and free of maintenance
(available at SureHands)
2x 12 Vdc/9 Ah
Batteries RC handcontrol 3 x 1,5 V AAA LR03
Number of hoists with fully-charged batteries
160 with 220.46 Lbs / 100.00 kg over 39.37 inch /
1.00 m
Acceleration and brake (soft start/stop) electronic
Cover ABS
Corrosion protected against corrosion
Emergency switch present
Emergency down mechanical
Sound 58 dB (A)
Battery indication ceiling motor Acoustic and visual
