Troubleshooting p. 19
USER GUIDE CEILING MOTOR
■ Make sure that the metal clip is aligned with the gray cover.
■ Push the cover onto the Ceiling Motor until it is fixed in place.
9.4. Replacing batteries
■ First remove the cover, as described in the above instructions.
■ Detach the battery wires.
■ Unscrew the left screw from the battery holder +/- 10mm so that the
battery holder can move freely and hang down.
■ Remove the batteries and replace them in the same position.
