USER GUIDE CEILING MOTOR
■ Check the polarity when connecting the batteries.
■ Attach the red wire to the plus pin (+) of battery 2
■ Attach the black wire to the minus (-) of battery 1
■ Connect the minus (-) of battery 1 and the plus of battery 2 using
the purple wire.
■ Reattach the cover (See 9.3 'Assembling the cover' - (See 9.3 "As-
sembling the cover" - p. 18)
9.5. Replacing batteries of the IR
handcontrol
■ Using a screwdriver, unscrew the screws of the battery cover at the
back of the IR handcontrol and insert 3 Alkaline batteries LR03
(AAA) 1.5V. To insert the batteries, please refer to the instructions
at the bottom of the battery slots.
■ Double check the polarity!
■ It is important to use long-life Alkaline batteries which are protected
against battery acid leaks.
