1 123.00021.035 2 Plug
2 9001641 2 Shock absorber 220 mm
3 00000.2104 4 Washer flat 3XD M10
4 00000.4110 2 Hex. bolt M10x70 D931/8.8 vz
5 001.03010.001 2 Hex. bolt M10x40
6 9000072 1 Battery container
7 00000.1700 2 Locknut M5 D985/8/VZ
8 00000.2001 2 Washer
9 00000.4038 2 Cil cap screw. inn. zk M5X10 VZ
10 9002714 1 Battery box
11 001.03030.001 2 M8x25 bolt with dog point
12 9002710 2 Motor suspension bearing
A - - See 017: Suspension arm and motor
