WG‐500PHotspotinaPrinter
53

PRODUCT=WG-500P;VER=2.00.00;LOGNAME=BLA; DATE=07Mar26;
TIME=15:23:32;WANMAC=09-00-0e-00-00-01;
LANMAC=09-00-0e-00-00-02; WLANMAC=09-00-0e-00-00-03;
IP_ADDRESS=210.66.37.21;USER_NAME=username;
BILL_TYPE=Cash,
BILL_AMOUNT= USD50.00
Billing Type= Cash | Credit_Card； Billing Amount = xx.xx
Currency = AUD | CHF | EUR | GBP | JPY | RIY | USD……
ClickApplybuttontosavethenewsettingsandthesuccessdialogboxappears.Click
onBacktoreturntoLogssettingscreen.
3‐2‐3‐2  SessionTrace
SessionTraceisanintelligentfunctiontohelpserviceprovidertotraceeveryuser’s
accessbehavior.When“sessiontrace”isenable,thesystemwillcollectinformation 
such like destination IP, destination port, source IP, source MAC, source port by
every user and send the collected information in text format file to specified TFTP
serverorEmailServer.

Figure3‐2‐23SessionTraceSettingScreen
