H&S 4112 - Set-Up & Assembly

-14-
SET-UP & ASSEMBLY
NOTE: Determine right or left side of the wheel rake by viewing it from the rear. If instructions or
parts lists call for hardened bolts, refer to Cap Screw Torque Values chart.
1. Assemble the rake or check the rake for proper assembly and adjustment. Make sure that all
bolts are tightened.
2. Attach the wheels with tires, using the lug nuts furnished and torque the mounting hardware to
95 ft./lbs. of torque. Check wheel bolts periodically thereafter.
3. Check tires and inate to the recommended pressure. (6.70 x 15 to 36 pounds.)
4. Lubricate the rake completely (See Lubrication Chapter in this Manual).
5. Tooth bolts must be torqued to 40 ft./lbs. to help prevent excessive tooth breakage.
 Re-torqueraketoothboltsaftertherst100acres.Checkperiodicallythereafter.
BF12HC ONLY
