SET-UP & ASSEMBLY
NOTE: Determine right or left side of the wheel rake by viewing it from the rear. If instructions or
parts lists call for hardened bolts, refer to bolt torque chart.
1. Assemble the rake or check the rake for proper assembly and adjustment. Make sure that all
bolts are tightened.
2.
Attach the wheels with tires, using the lug nuts furnished and torque the mounting hardware to
95 ft./lbs. of torque. Check wheel bolts periodically thereafter.
3. Check tires and inflate to the recommended pressure. (6.70 x 15 to 36 pounds)
4. Lubricate the rake completely (See
Lubrication Chapter in This Manual).
5. Tooth bolts must be torqued to 40 ft./lbs. to help prevent excessive tooth breakage.
Re-torque rake tooth bolts after the first 100 acres. Check periodically thereafter.
-12-
