H&S HAY MACHINE II - Page 22

FIGURE 1
MAIN FRAME ASSEMBLY
ITEM PART NO. DESCRIPTION
1. BFR129 Hitch
2. ES7 Hair Pin
3. BFR5 Hitch Pin
4. T200 Pole
5. T223 Hose Clamp
6. HE42 Hose Clamp
7. BFR319 “I” Bolt
8. T201 Spring
9. T202 Pole Latch Pin
10. T203 Latch Handle
11. T245 Latch Bolt 3/8” X 3” Gr. 5
12. T204 Pole Pivot Pin
13. T205 Tine Pitch Handle
14. 33SV65 Bearing
15.
T206 Drive Belt Shield
16. T207 Reel Lift Crank
17. T208 Lifting Bolt
18. T209 Poly Washer
19. T210 Lifting Chain
20. T211 Lifting Shaft
21. T212 Main Frame
22. T213 Left Outer Reel Slide
23. T214 Left Inner Reel Slide
24. T215 Safety Chain
25. T216 Yoke Pin
26. 3G22 Roll Pin
27. T217 Yoke
28. 12V59 Roll Pin 3/8” X 2-3/4”
29. T218 Width Adjuster
30. T219 Adjustment Spacer
31. F56 Clip Pin
32. T220 Right Inner Reel Slide
33. T221 Right Outer Reel Slide
34. BFR344 Foam Insert
35. T222 Spindle
36. BFR57 Seal
37. BFR58 Inner Bearing
* BFR59 Inner Race
38. BFR60 Hub
39. BFR62 Outer Bearing
* BFR61 Outer Race
40. BFR63 Washer
41. BFR65 Cotter Pin
42. BFR64 Nut
43. BFR66 Hub Cap
44. BFR67 Wheel 15 X 5
45. BFR295 Snap Hook
46. 23N67 Hose Clamp
47. 12V66 Bolt 5/16” X 3/4”
NOTE: * (MEANS NOT SHOWN)
-21-
