H&S HAY MACHINE II - Page 24

FIGURE 2
REEL ASSEMBLY
I
TEM PART NO. DESCRIPTION
1. T74 LH Reel Cross
2
. T75 Center Reel Cross
3. T76 RH Reel Cross
4. T784-8 Reel Pipe (8 Hole)
* T784-9 Reel Pipe (9 Hole)
5. T78 Bronze Bushing 1-1/4” ID (8)
6. T79 Bronze Bushing 1-1/4” ID (4)
7. T116 Nut 5/16”
8. T115 Setscrew for Reel
9. T123 Bolt 3/8” X 2-1/4” Gr. 5
10. T82 Rubber Mounted Teeth
11. B68 Lock Washer 3/8”
12. K60 Nut 3/8”
13. T114 Bolt 3/8” X 2” Gr. 5
14. T85 Center Stub Shaft
15. T246 Spacer 3”
16. T224 Reel Shaft
17. T254 Spacer 1-1/4”
18. T72 Cotter Pin
19. T73 Washer
20. T225 Pulley
21. T261 V-Belt
22. T40 Bearing
23. 17G43 Bolt 1/2” X 3-1/2”
24. T227 Drive Belt Tightener
25. K156 Pulley
26. T252 Pulley
27.
T62 Bolt 5/8” X 1-1/2”
28. T64 Cam Assembly
29. T60 Nut 5/8” Lock
30. T63 Bronze Bushing 1-3/8” ID (2)
31.
T59
Cam Short
Arm
32. T58 Bronze Bushing 3/4” ID (4)
33.
T122 Steel Bushing
34. T60 Nut 5/8” Lock
35. T52 Bronze Bushing 3/4” ID (8)
36.
T66
Cam Roller Bearing
37. T65 Bolt 5/8” X 4”
38. 9S17 Nut 1/2” Lock
39. ST36 Spring
40.
T67
Long Grease Zerk
41. T228 Bearing Mount
43. T19 Bolt 3/8” X 2”
44. T53 Cam Long Arm
45.
T52
Bronze Bushing (8)
46. T50 Sq. Key 5/16” X 2”
47. T83 RH Stub Shaft
48. T80 LH Stub Shaft
-23-
