H&S HAY MACHINE II - Page 26

FIGURE 3
RAKE BEAM ASSEMBLY
ITEM PART NO. DESCRIPTION
1. BFR224 Bolt 1/2” X 4-1/2” Gr. 5
2
. BFR226 Poly Roller
3. R29 Nut 1/2”
4. BFR269 Bronze Washer (1)
5. X26 Full Thread Bolt 3/8” X 3” Gr. 2
6. BFR267 Brake Pad
7. BFR268 Brake
8. BFR625 Bronze Bushing (2)
9. BFR280A Wheel - Spoked
10. BFR270 Complete Fork
11. BFR271 Nylon Lock Nut 1”
12. BFR272 Spacer
13. BFR273 Seal
14. BFR274 Bearing
15. BFR275 Race
16. BFR276 Hub (Only)
17. BFR277 Tire
18. T255 Axle Roller
19. BFR32 Hub
20. BFR339 Lug Bolt
21. T164 Inner Bearing
* T165 Inner Race
22. T163 Seal
23. BFR278 Spacer
24. BFR279 Axle Shaft
25. BFR179 Washer
26. BFR313 Roll Pin
27. T229 Hydraulic Lift Bracket
28. T72 Cotter Pin
29. PB13 Cylinder Pin
30. T230 Rake Beam
31. T168 10mm X 25mm Bolt
32. BFR229 Steel Washer
33. BFR221 Poly Washer
34. S99 “O” Ring
35. G16 Bushing
36. BFR230 Spacer
37. 3G22 Roll Pin
38. T231 Rake Wheel Arm
39. BFR36 Rake Wheel Spindle
40. BFR138 Spring
41. BFR140 Chain
42. BFR82
Pipe Clamp
43.
BFR256
Spring Bracket
44.
BFR83
Pipe Clamp
45. T166 10mm Nut
46. T232 Lifting Pipe
47. BFR31 RH Rake Wheel
48.
T166 10mm Nut
49. T175 10mm X 25mm Carr. Bolt
50. T176 Rake Wheel Tooth
51. T178 Rake Tooth Clip
52. T179 Rake Wheel Center
53. T169 Cotter Pin
54.
T173
Hub Cap
55. T172 Nut
56. T170 Outer Bearing
* T171 Outer Race
57. T143 Cyl. Pin
58. T144 Clip Pin
59. T177 Outer Ring
NOTE: *
(MEANS NOT
SHOWN)
