H&S HAY MACHINE II - Page 32

FIGURE 7
OPTIONAL FOURTH WHEEL ASSEMBLY
ITEM PART NO. DESCRIPTION
1. BFR31 RH Rake Wheel
2
. BFR229 Steel Washer
3. BFR221 Poly Washer
4. S99 “O” Ring
5. G16 Bushing
6. BFR230 Spacer
7. 3G22 Roll Pin
8. T231 Rake Wheel Arm
9. BFR36 Rake Wheel Spindle
10. BFR138 Spring
11. BFR140 Chain
12. BFR256 Spring Bracket
13. T248 Lifting Pipe
14. T251 Rake Beam Extension
15. T249 Rake Beam Extension Bracket
16. T284 Latch
17. T166 10mm Nut
18. T175 10mm X 25mm Carr. Bolt
19. T176 Rake Wheel Tooth
20. T178 Rake Tooth Clip
21. T179 Rake Wheel Center
22. T173 Hub Cap
23. T172 Nut
24. T170 Outer Bearing
* T171 Outer Race
25. BFR32 Hub
26. T164 Inner Bearing
*
T165
Inner Race
27. T163 Seal
28. T168 10mm X 25mm Bolt
29. T166 10mm Nut
30.
T169
Cotter Pin
31. T253 3/8” X 4” Bolt Gr. 5
32. RG174 5/8” X 5” Bolt Gr. 5
33.
BFR82
Pipe Clamp
34. T177 Outer Ring
35. BFR334 Foam Filler
36. T285 Latch Fastener
NOTE: * (MEANS NOT SHOWN)
-31-
