-24-
INSTRUCTIONS FOR ORDERING PARTS
All service parts should be ordered through your authorized H&S dealer. He will be able to give you faster
service if you will provide him with the following.
1. Model & Serial Number - Both can be located on the front main panel - below control lever.
2. All reference to left or right apply to the machine as viewed from the rear.
3. Parts should not be ordered from illustration only. Please order by complete part number.
4. If your dealer has to order parts - give shipping instructions.
VIA truck - large pieces (please specify local truck lines)
VIA United Parcel Service (include full address)
PLEASE RECORD NUMBERS FOR YOUR UNIT FOR QUICK REFERENCE
ABOUT IMPROVEMENTS
H&S IS CONTINUALLY STRIVING TO IMPROVE ITS’ PRODUCTS.
We must therefore, reserve the right to make improvements or changes whenever it becomes practical to
do so, without incurring any obligation to make changes or additions to the equipment previously sold.
ITEM PART NO. DESCRIPTION
1. S69 Cross Apron Pan Extension
2. S70 Spacer
3. S71 Pan Extension Carrier
4. S72 Return Pan Extension
5. 4C9 Lock Collar
6. 4C7 Bearing Flange
7. 4C8 Bearing
8. S73 Cross Apron Idler Shaft
9. S74 Tightener Bracket
10. L10R24 8 Tooth Sprocket
11. 5B10 1/4’’ x 1’’ Woodruff Key
12. S75 Tightener Bolt
13. S76 Tightener Panel Rear
14. S77 Tightener Panel Front
15. S78 PTO Holder Rubber Tab
16. S354 PTO Holder
17. X85 Bearing Flange Sheared
18. K132 3/8’’ Spacer
19. S223 Cross Conveyor Hold down
20. S357 Front Drive Chain 193 Pitch #50
21. K101 Tightener Sprocket 17T
22. S82 Sprocket 24T
23. ES10 5/16’’ x 3’’ I-Bolt
24. ST36 Spring
25. S459 Tightener Bracket
26. S391 Shear Hub
27. S392 Sprocket 24T
28. S393 Bronze
29. K89 Idler Sprocket 20T
30. K90 Bearing
31. S87 Cross Apron Shaft Guard
32. K92 Snap Ring
33. S390 Cross Apron Drive Shaft
34. S89 Cross Conveyor
35. K122 550 Offset Link Cross Conveyor
36. K120 550 Slat with Attachment Links
37. K121 550 Connector Link Cross Conveyor
38. S394 Snap Ring
39. RGB38 Shear Bolt 5/16’’ x 1’’ GR.2
* X60 #50 Offset Link
* X61 #50 Connector Link
40. A34 Washer 1/2”
41. S468 Washer
42. 16SV126 Counter Sunk Bolt 2”
43. R65 Spacer 3/8”
44. S467 Counter Sunk Bolt 2-1/4”
45. K79 Eye Bolt
NOTE: * (Means Not Shown)
-37-
FIGURE 4
CROSS APRON AND DRIVE ASSEMBLY
To Next Page
