DECAL LOCATION
Your H&S H D 7+4 Industrial Two-Way Unloading Forage Box was manufactured with operator safety in
mind. Located on the forage box are various decals to aid in operation, and warn of danger or caution areas.
Pay close attention to all the decals on your forage box.
DO NOT REMOVE ANY OF THESE DECALS. IF DECALS ARE LOST, DAMAGED, OR IF
FORAGE BOX IS REPAINTED, REPLACE DECALS. REMEMBER: DECALS ARE FOR
YOUR PROTECTION AND SAFETY.
Listed below are the decals on your H D 7+4 Industrial Two-Way Unloading Forage Box. These decals may
be ordered individually by part number or by ordering a complete set.
ITEM PART NO. DESCRIPTION
A 1494A (5) Warning - Do Not Operate
AA 53102 (2) Door Locks
B 1494K (3) Warning - Do Not Remove Shields
BB 1494O (3) Warning - Emergency Stop Function
C 1494Q Warning - Operator Position
CC 1494I (2) Danger - Keep Out
D H&S Patent Numbers
E 5896B Danger - Rotating Driveline
EE FEMA
F Serial Number
FF 1494F Danger - Never Enter
G 1-1-91 Beater Engage/Disengage
GG 2495 Warning - Keep Children Away
H 7+4-2191 Clean Out
HH 11599 Warning - Stay Clear of Hydraulic Lines
I 1494P Danger - Stay Clear of Power Lines
II 1494J Warning - Do Not Hand Clean
J Weasler Danger - PTO (H&S Decal 1494L)
JJ (3) H&S HD7+4
K Amber Reflector
KK 5696E Engage
L 1494H (3) Danger - Stay Clear
LL 5696D Disengage
M 72203A Warning - Help Avoid Injury
O 104-3185 Push This Panel
P 5896C Warning-To Prevent Serious Injury
Q 103-3185 Emergency Stop
R 120-2177 (2) Pull to Stop
S (2) H&S Decals (sets)
T Red Reflector
U 1494C (3) Warning - Moving Parts Under (5 on 18’’ Box)
V 7+4-3185G Entering Forage Box
X 112-11176 Shear Bolt
Z 31300 (2) Drive Pin Instructions
7+42805IFR Complete Set of Decals
Paint - H&S Red
ZX21 Gallon
ZX22 Quart
ZX23 Pint
-22-
ITEM PART NO. DESCRIPTION
1. S364 Shifter Handle
2. X43 Cotter Pin
3. S91 Shifting Pipe Bracket
4. S360 Speed Selector Panel
5. S365 Front Center Angle
6. S366 Shifting Pipe (Apron)
7. S367 Shifting Rod (Beater)
8. S96 Shifting Bracket
9. S97 Stationary Sheave
10. S295 Sliding Sheave
11. S99 O-Ring
12. S100 Thrust Bearing
13. S101 #40 Chain 5 Pitch
14. S102 #40 Connector Link
15. S103 Linkage Rod
16. S104 Adjustment Block
17. S105 Variable Speed Shifter
18. R10 1/2’’ x 1-1/4’’ Bolt GR.5
19. S106 5/16’’ x 2-3/4’’ Expansion Pin
20. S296 Sheave Pin
21. S108 Variable Speed Belt
22. S109 Spring
23. S110 1/4’’ x 2’’ Expansion Pin
24. S111 Spring
25. 9S17 1/2’’ Lock Nut
26. S285 Beater Clutch Washer
27. S112 Beater Clutch Bracket
28. S113 Beater Clutch Long Arm
29. S114 Beater Clutch Short Arm
30. ST58 Clutch Yoke
31. S115 Beater Clutch Pin
32. S116 Beater Clutch Sprocket
33. S117 Beater Clutch Bushing
34. S118 Beater Shield Top
35. S119 Beater Side Shield
NOTE: * (Means Not Shown)
ITEM PART NO. DESCRIPTION
36. S120 Main Side Shield
37. D58 Shield Angle
38. S121 Side Shield Bottom
39. S122 Clip Pin Cable
40. F32 U-Bolt
41. S123 Shield Latch Bracket
42. S234 Shield Brace
43. F56 Clip Pin
44. S333 Front Upright Shield
45. S334 Front Shield
46. BFR319 I-Bolt
47. S359 Edging 38’’
48. X192 Front Shield Latch (Rubber)
49. X193 Latch Catch Bracket
50. X194 Latch Mounting Bracket
51. X195 Pin
52. S131 PTO Rubber Shield
53. S221 Spring Shift Bracket
54. S222 Shifting Spring
55. S220 Shifting Spring Rod
56. K94 Spacer
57. T16 1/4’’ Flat Washer
58. S290 Shifter Handle Pipe End
59. S291 Spring Pin Collar
60. S292 Spring
61. S293 Spring Collar
62. 4C9 Lock Collar
63. K92 Snap Ring
64. K90 Bearing
65. 17G141 Bolt 3/8’’ x 1-1/4’’ GR.5
66. X111 Bolt 3/8’’ x 1’’ GR.5
67. S328 Edging 3-1/2’’
68. S346 Mounting Bracket
69. S403 Handle Grip
* S368 Complete Shifter
-39-
FIGURE 5
SHIELDS - BEATER CLUTCH - BELT DRIVE
