Grease locations and recommended intervals are as follows:
-27-
LUBRICATION
Grease the Front Steering Mechanism as needed, at least annually.
2 Zerks - 1 on each Tensioner
Annually Only
4 Zerks - Each Hoop Roller Support
Every 20 Hours of Operation
Spindle
Pivot
Spindle
Pivot
Tie Rod Ends Pole Pin Tie Rod Pole Pivot
Center Pivot
GREASE FITTINGS
There are numerous grease fittings on the LINEWRAP. If lubricated properly and often enough, it will
prolong the life of your rake. Grease daily during normal use and before and after storage and after power
washing. Use a good grade of high quality grease. Make sure that grease comes out around the shaft on
sleeve type bearings. Wipe off excessive grease to prevent accumulation of chaff or grit around the
bearing. Replace any missing or plugged grease fittings.
