1-888-628-1730 • Mini Maxx Installation Manual 9
Mini Maxx & Windshield Mount
OBDII Adapter Plug
OBDII Port
Power Cable
(Optional)
Fuse Box
Fire wall grommet
MOST APPLICATIONS
INSTALLATION OVERVIEW
The installation overview illustrates a totally installed and functional Mini Maxx system. This overview is
meant to help reference the general location of installed parts and pieces of the Mini Maxx. Notice that there
are dierent overview diagrams. Use the correct diagram for your truck. For more complete wiring diagrams
and instructions, please see vehicle specic features starting on page 30.
OBDII Port
OBDII Adapter Plug
Power Wire
(Optional. To purple
ignition
wire under dash)
MINI MAXX &
Windshield mount
HDMI Cable
FORD POWER STROKE ‘08’10
MINI MAXX INSTALLATION
To Next Page
