3. Reset the reversing valve (1) after the test is completed.
Test emergency lowering function
1. Start the lifting function and lift the platform to a certain height.
2. Pull out the emergency lowering handle (on the rear of the frame).
Result: The platform should be lowered and will stop lowering after releasing the handle. The
alarm does not sound when the platform is lowered.
Test level sensor
Use the platform control handle to control the equipment on the ground, do not
stand inside the platform to operate.
1. Lower the platform safely.
2. For 65XEN, 78XEN, 80XENS and 100XENS:
Place two wooden blocks with the dimensions 120mm×25mm (W×H) under the two wheels on
the left/right side of the machine, and then drive the machine onto these two wooden blocks.
For 80XEN, 100XEN, 120XEN and 140XEN:
Place two wooden blocks with the dimensions 150mm×35mm (W×H) under the two wheels on
the left/right side of the machine, and then drive the machine onto these two wooden blocks.
For 160XEN and 160XENS:
Place two wooden blocks with the dimensions 150mm×40mm (W×H) under the two wheels on
the left/right side of the machine, and then drive the machine onto these two wooden blocks.
3. Switch the driving function to the platform lifting/lowering function and press the handle to lift
the platform by about 2m.
Result: The platform should stop moving and the tilt alarm should be sounded. “LL” will be
displayed on the platform and ground control panel.
4. Lower the platform, switch to driving function, remove the working platform, and then the
wooden blocks.
5. For 65XEN and 78XEN:
Place two wooden blocks with the dimensions 120mm×45mm (W×H) under the two wheels on
the front/rear of the machine, and then drive the machine onto these two wood blocks.
