The battery state will affect the machine performance. When “Low Battery” is
displayed on the platform control panel, the driving speed and lifting speed of the machine will
be reduced.
Select driving speed
In the retracted position, the driving controller can work in two different driving speed modes.
When the low speed button (tortoise speed indicator) lights up, the low driving
speed mode is activated. If it does not light up, the machine will run in high
driving speed mode by default.
Press the low speed button to select the required driving speed.
When the platform is lifted to the position where the anti-rollover device is
enabled, the low speed button (tortoise speed indicator) lights up,
indicating that the lift is running in low driving speed mode.
Battery leveldisplay
Check the battery level from the LED on the platform control handle.
Table of battery levels
Battery Level
Remaining
Capacity Ratio
Description
6 bars
90-100%
Full battery
5 bars
70%
70% Battery capacity
4 bars
50%
50% Battery capacity
3 bars
30%
30% Battery capacity
2 bars
20%
The battery is low and must be charged 
immediately.
1 bar
10%
Extremely low battery, the platform slows down
or even stops working.
7.4 Extend and retract the platform
Extend and retract the platform
1. Depress the pedal.
2. Hold and carefully push the extensible platform guardrail to extend platform.
Do not stand on the extended part of the platform when extending it. The
extensible platform can be positioned at the three slots, do not stand on the extensible platform
