8.4 8.4 Replace Replace hydraulic hydraulic oiloil
Procedure:
Procedure:
––
Remove the hydraulic unit from the truck.Remove the hydraulic unit from the truck.
–– Place a container under the hydraulic unitPlace a container under the hydraulic unit
to pick hydraulic oil.to pick hydraulic oil.
–– Loosen hoop (2).Loosen hoop (2).
––
Take out the hydraulic power assembly (1)Take out the hydraulic power assembly (1)
from oil tank (3).from oil tank (3).
–– Pour the hydraulic oil from the oil tank (3)Pour the hydraulic oil from the oil tank (3)
into the appointed waste oil collectinto the appointed waste oil collect
container, and then clean the oil tank.container, and then clean the oil tank.
–– Install the hydraulic power assembly to theInstall the hydraulic power assembly to the
oil tank and then retighten with the hookoil tank and then retighten with the hook
（（T= 9N.mT= 9N.m））..
–– Screw out the filler cap (4) of the oil tank,Screw out the filler cap (4) of the oil tank,
add hydraulic oil to specified mark with theadd hydraulic oil to specified mark with the
help of funnel.help of funnel.
–– Re- screw on the filler cap, and clean theRe- screw on the filler cap, and clean the
residual oil on the outside of the hydraulicresidual oil on the outside of the hydraulic
unit.unit.
Replacing oil finishes. Then install the Replacing oil finishes. Then install the hydraulichydraulic
unit to the truck.unit to the truck.
