41
Lifting assy
Service
item
Service required
Tool
D
W
M
T
S
Chain & chain wheel
Check chain for tension, damage or
rust
〇
〇
〇
〇
〇
Add lubrication for chains
〇
〇
〇
Check chain wheel for deformation
or damage
〇
〇
〇
Check chain wheel bearing for
looseness
〇
〇
〇
Pin shaft lubrication
〇
〇
〇
Lifting cylinder
Check piston rod, rod screw and
connection for looseness,
deformation or damage
Test
hammer
〇
〇
〇
〇
〇
Check for operation
〇
〇
〇
〇
〇
Check for oil leak
〇
〇
〇
〇
〇
Check lifting cylinder fixed bolt for
looseness.
〇
〇
Mast & fork carriage
Check welded parts of beam and
outer and inner masts for defective,
cracks or damage
〇
〇
〇
Check outer and inner masts for
defective weld, cracks or damage
〇
〇
〇
Check for defective weld, cracks or
damage of fork carriage
〇
〇
〇
Check roller bearings for looseness
〇
〇
〇
Check rollers, roller pins and welded
parts for cracks or damage
〇
〇
〇
Fork
Check forks for damage,
deformation or wear
〇
〇
〇
Check fork base and hook welding
for defective cracks or wear
〇
〇
〇
Attach
ment
Check if normal.
〇
〇
〇
