68
wooden block under each side of outer
mast;
⑥ Tilt mast forward until front wheels are
raised from surface;
Caution
Do not loose nuts before the front wheels
leave the ground.
⑦Support truck by putting wooden blocks
under both sides of the front truck frame.
Stop the engine.
⑧ Take out the wheel nuts and replace the
front wheel.
Caution
a. When removing tire from wheel rim, do
not remove rim set bolts and nuts before
releasing air;
b. Make sure that wooden blocks used to
support lift truck are solid, one-piece units.
c. Never get under forklift while it is
supported only by wooden blocks.
⑨ Retighten the wheel nut temporarily.
⑩ Start the engine, and take out the
wooden block.
○
11
Tilt backward the mast and lower down
the mast slowly, then take out the wooden
block under the outer mast and rear wheel.
○
12
Retighten the wheel nut with correct
torque.
○
13
Adjust tire pressure to specified value.
Rear wheel
① Park forklift trucks on level concrete.
② Pull the parking brake lever and place
chocks before front wheels to prevent
movement of forklift.
③Put the lifting jack under the
counterweight.
Caution：Make sure the jack capacity is
greater than 2/3 of service weight of forklift.
④ Loosen wheel nuts 1-2 turns by turning
them counter-clockwise.
Warning
Do not remove wheel nuts until rear tires
are raised from ground.
⑤ Raise the forklift with jack until rear
wheels off the ground. Support forklift truck
by putting additional wooden blocks under
both sides of the front truck frame as shown
below.
⑥ Take out the wheel nut of rear wheel, and
then replace the wheel.
To Next Page
