www.ihanil.com
10/26
3. Installation
3.3 HyperCOOL Connection
[HyperCOOL as a 'Freezer Dryer']
Rubber Valve Closed
Tube Connection to Vacuum Pump
Mains Inlet
Vacuum Pump to Power Outlet
Vacuum Pump to HyperCOOL
Power Outlet for Vacuum Pump
Rubber Valve Open
