3. Installation
3.3 HyperCOOL Connection
[HyperCOOL (HC-CPP) as a ‘Cold Trap’]
[Preparation]
DEFROST should be performed only when the vacuum pump is o.
While DEFROST function is activated, HyperVAC (the vacuum concentrator) should
be run at lower than 1,000 rpm not to turn on the vacuum pump.
① Tube Connection to Vacuum Pump
② Mains Inlet
③ Vacuum Pump to HyperCOOL
④ Vacuum Pump to Power Outlet
⑤ Mains Inlet
⑥ HyperCOOL to HyperVAC
①
②
③
④
⑤⑥
