5
1) Liquid Crystal Display
2) Measurement range selection keys
3) EC calibration knob
4) Manual temperature compensation knob
5) Temperature selection key
6) On/Off key
Range
0.0 to 199.9 / 0 to 1999 µS/cm
0.00 to 19.99 / 0.0 to 199.9 mS/cm
Resolution
0.1 / 1 µS/cm
0.01 / 0.1 mS/cm
Accuracy
(@ 20 °C/68 °F)
±1% Full scale
excluding probe error
Typical EMC Deviation ±2% Full Scale
Calibration Manual, 1 point, through EC knob
Temperature
Compensation
Manual, 0 to 50 °C (32 to 122 °F) with
β =2%/ °C
Probe (included) HI76301D with 1m (3.3’) cable
Environment 0 to 50 °C (32 to 122 °F); RH max 100%
Battery Type 1 x 9V alkaline
Battery Life Approx. 100 hours of continuous use
Dimensions 145 x 80 x 36 mm (5.7 x 3.1 x 1.4 “)
Weight 230 g (8.1 oz.)
FUNCTIONAL DESCRIPTION &
SPECIFICATIONS OF HI8633
