User’s Manual
APPENDIX
SPECIFICATIONS
Driving system TFT Color LCD
Size 18.5"
LCD Panel
Pixel pitch 0.3 mm(H) x 0.3mm(V)
H-Frequency 24KHz – 61KHz
Video
V-Frequency 56 – 75Hz
Display Colors 16.7M Colors
Max. Resolution 1366 x 768 @60Hz
Plug & Play
VESA DDC2B
TM
, DPMS
ON Mode 20W (Typical)
Power Saving Mode ≤1W
Power consumption
OFF Mode ≤0.5W
Audio output Rated Power 1.0W rms (Per channel)
Input Terminal VGA
Maximum Screen Size
Hor. : 409.8mm
Ver. : 230.4mm
Power Source 100~240VAC,50±3Hz,60±3Hz
Environmental
Considerations
Operating Temp: 5° to 35°C
Storage Temp.: -20° to 60°C
Operating Humidity: 20% to 85%
Dimensions
440.4 (W) x 343.5(H) x 160.1(D) mm
17.3 ”(W)×13.5 ”(H)×6.3 ”(D)
Weight (NW) 3.4 kg(7.5lb)
*** The above specification is subject to actual product specification and is subject to change
without prior notice.
NOTES:
The Maximum Resolution will depends on the display card supporting. Related issue can refer to
www.hannsg.com FAQ section.
21
