5.2 Electric Block Diagram
5.2.1 Main Board
LCD interface
(
CN101
)
Scalar TSUMO5PHJ
(Include MCU, ADC, OSD)
(U401)
D-Sub
Connector
(CN405)
H sync
V sync
RGB
Crystal (14.318MHz)
(X401)
EEPROM
M24C02
(
U404
)
EEPROM
24LC16
(U403)
DVID
Connector
(
CN406
)
RGB
DCLK+
DCLK-
EEPROM
M24C02
(
U405
)
