19" LCD Color Monitor HSD HG191D
38
White Screen
White screen
Measure C717 (+) =5V
Checks Q704, Q705,
Q706 are broken
Check CN101 connector or
solder normal?
Replace CN101 or
re-solder
Replace PANEL
OK
Replace Q704,
Q705, Q706
NG
NG
NG
Check X401
OK
Re
p
lace U401
Re
lace X401
NG
OK
OK
