User’s Manual
11
MAKING CONNECTIONS
CONNECTING TO A PC
You can setup your monitor with the below suggested connections. Ensure your monitor is off during
this process.
1. Connect one end of the HDMI cable to the back of the monitor and connect the other end to the
computer’s HDMI port.
2. Connect one end of the DP cable (optional) to the back of the monitor and connect the other end
to the computer’s DP port.
3. Connect the audio cable between the monitor's audio input and the PC's audio output (green
port).
4. Plug one end of the AC power cord to the LCD monitor’s AC input socket, and the other end to
Wall outlet.
5. Turn on your monitor and computer.
.
Figure.2. Connecting to a PC
1 USB IN Input 2 USB OUT
3 Power AC Input 4 DP Input
5 HDMI Input 6 VGA Input
7 LINE IN 8 Earphone
