Installation
Page EN-27
– Veneers or plastic coverings on the built-
in furniture require heat-resistant adhesive
(100 °C). If the adhesive and surfaces are
not heat-resistant, the covering may warp
and come loose.
– An intermediate shelf is required if a drawer
is to be installed below the oven.
– The installation recess may not have a rear
panel, at the most it may have an add-on
edge measuring no more than 50 mm.
– The built-in cabinet can be equipped with
either ledges/rails or an intermediate shelf
with ventilation cut-out.
– The installation recess must have the fol-
lowing minimum dimensions
– Installation under a worktop
❶
min. 600 mm
➋ 560 mm
❸ min. 570 mm
➍ min. 600 mm
❺ max. 50 mm
❻ max. 50 mm
– Installation in an upright cabinet
❶ min. 585 mm, max. 595 mm
➋ 560 mm
❸ min. 585 mm (incl. ➐)
❺ max. 50 mm
❻ max. 50 mm
➐ min. 35 mm
➋
➊
➍
Installation under a worktop
❺
❻
❻
➌
Installation in an upright cabinet
➋
➌
➊
➎
➐
