Hansen HA4A series User Manual

PARTS LIST ¾" THROUGH 1¼" (20 MM THROUGH 32 MM)
ITEM
DESCRIPTION
QTY
PART NO
Piston Kit consists of:
75-1019
1
Piston
1
75-0191
2
Piston Seal
1
75-0353
4
Adapter Gasket
1
75-0489
20
Flange Gasket
2
70-0132
V-Port/Seat Kit ¾"*
75-1020
V-Port/Seat Kit 1"*
75-1021
V-Port/Seat Kit 1¼"*
75-1022
Above kits consist of:
3a
3
/4" V-Port/Seat
1
75-0194
3b
1" V-Port/Seat
1
75-0193
3c
1
1
/4" V-Port/Seat
1
75-0192
5
Closing Spring
1
75-0287
6
Bottom Cap O-ring
1
75-0183
*HA4AK AND HA4AO V-PORT/SEAT KITS
DESCRIPTION
PART NO
V-Port/Seat Kit
3
/4"
75-1129
V-Port/Seat Kit 1"
75-1130
V-Port/Seat Kit 1
1
/4"
75-1131
Above kits contain V-Port/Seat, bottom cap O-ring, and a 5
psid (.35 bar) closing spring (Part 75-0622). A lighter spring is
available (Part 75-0287).
ITEM
DESCRIPTION
QTY
PART NO
Gasket Kit consists of:
75-1023
4
....Adapter Gasket
1
75-0489
6
....Bottom Cap O-ring
1
75-0183
7
....Stem O-ring
1
70-0010
8
....Stem Washer
1
70-0026
9
....Stem Packing
1
70-0025
10
....Packing Nut
1
70-0019
13
....Seal Cap O-ring
1
70-0011
20
....Flange Gasket
2
70-0132
....Solenoid Tube Gasket
1
70-0301
....Port Gasket & O-ring
3
75-1071
11
Manual-Opening Stem
1
75-0164
12
Seal Cap
1
50-0411
14
Gauge Port Plug (
1
/4" NPT)
1
75-0189
15a
Adapter, 1 Port
1
75-0163
15b
Adapter, 3 Port
1
75-0162
16
Adapter Bolts, socket cap
4
75-0190
17
Bottom Cap
1
75-0155
18a
Body
3
/4", 1"
1
75-0156
18b
Body 1
1
/4", 2-Bolt
1
75-0154
19
Flange (Various)
2
FACTORY
21
Flange Bolt (
5
/8"-11x2.75")
4
70-0339
Flange Nut (
5
/8"-11)
4
70-0136
15
R429d
MAR 2002
