LIQUID CAPACITIES (U.S. GPM)
APPLICATION: REFRIGERANT PUMP RELIEF
REGULATOR (HA4AL)
PORT SIZE
R717
R22
P= 30 psi
P= 30 psi
(mm)
(2 bar)
(2 bar)
3
/ 4 "
(20)
45
30
1"
(25)
82
56
1
1
/ 4 "
(32)
114
78
1
1
/ 2 "
(40)
256
168
2"
(50)
324
230
2
1
/ 2 "
(65)
553
377
3"
(80)
733
505
Capacities assume no gas flashing. No capacity correction
required for temperatures between –40F (–40°C) and +40F
(+4.4°C).
OIL CAPACITIES (U.S. GPM)
APPLICATION: SCREW COMPRESSOR OIL
PUMP RELIEF REGULATOR (HA4AL)
PORT SIZE
OIL
P= 30 psi
(mm)
(2 bar)
3
/ 4 "
(20)
48
1"
(25)
87
1
1
/ 4 "
(32)
122
1
1
/ 2 "
(40)
260
2"
(50)
350
2
1
/ 2 "
(65)
574
3"
(80)
775
Capacities based on oil with less than 300 SSU viscosity.
HOT GAS DEFROST NOMINAL VALVE SIZING CAPACITIES
(DEFROSTING EVAPORATOR SIZE TONS)
R EFRIG.
APPLICATION
PORT SIZE (mm)
3
/4" (20)
1 " (25)
1
1
/4" (32)
1
1
/2" (40)
2 " (50)
2
1
/2" (65)
Hot Gas Solenoid *
9 to 15
15 to 28
28 to 39
39 to 73
73 to 106
106 to 165
R717
Defrost Relief
17 to 24
24 to 45
45 to 60
60 to 96
96 to 140
140 to 225
Regulator
Hot Gas Solenoid *
6 to 8
8 to 15
15 to 20
20 to 32
32 to 47
47 to 75
R22
Defrost Relief
6 to 8
8 to 15
15 to 20
20 to 32
32 to 47
47 to 75
Regulator
*Or an outlet pressure regulator with electric shut-off (HA4AOS).
Evaporator tons at 10F (5.6°C) TD (temperature differential), valve capacities are conservative. These capacities can be modified up
or down depending on type of evaporator, temperature, mass, frost thickness, defrosting time, etc. Typical for –20F (–28.9°C)
evaporator.
GAS CAPACITIES (TONS)*
(1 Ton= 12,000 Btu/hr= 3.517 kW= 3042 kcal/hr)
DISCHARGE GAS REGULATOR
HOT GAS BY-PASS TO SUCTION
R 717
R 22
R 717
R22
SIZE
+86F (+30°C)
+86F (+30°C)
+86F (+30°C)
+15F (–9.4°C)
+86F (+30°C)
+15F (–9.4°C)
Condensing
Condensing
(mm)
+140F (+60°C)
+140F (+60°C)
Condensing
Condensing
Condensing
Condensing
Discharge
Discharge
+140F (+60°C)
+15F (–9.4°C)
+140F (+60°C)
+15F (–9.4°C)
2 psid
5 psid
2 psid
5 psid
Discharge
Discharge †
Discharge
Discharge †
3
/4"**
(20)
17
27
6.1
9.5
88
27
32
12
1"
(25)
31
49
11
17
160
49
58
22
1
1
/4" (32)
44
69
16
24
224
68
81
31
1
1
/ 2 "
(40)
94
147
33
52
479
146
173
66
2"
(50)
126
197
45
70
643
196
232
89
2
1
/ 2 "
(65)
206
323
73
115
1054
321
380
146
3"
(80)
279
437
99
155
1424
434
513
197
4"
(100)
445
698
158
241
Hot gas bypass capacities are based on above given temperatures.
Liquid temperature is the same as condensing temperature.
5"
(125)
649
1017
230
361
Evaporator temperature +40F (+4.4°C) or less for +86F (+30°C)
6"
(150)
1108
1735
393
616
condensing; –22F (–30°C) evaporator for +15F (–9.4°C) condensing.
= Bypass from intermediate pressure at saturation temperature to booster suction.
* These capacities are not for hot gas defrost relief. See the chart in the middle of this page.
** Optional 25% and 50% reduced capacity ¾" (20 mm) plugs are available.
Discharge gas capacities are based on +15F (+10°C) evaporator temperature.
5
R429d
MAR 2002
