Hansen HA4A series User Manual

PARTS LIST 1½" THROUGH 4" (40 MM THROUGH 100 MM)
ITEM
DESCRIPTION
QTY.
PART NO
Piston Kit 1½", 2"
75-1025
Piston Kit 2½"
75-1026
Piston Kit 3"
75-1027
Piston Kit 4"
75-1028
Above kits consist of:
1a
Piston 1
1
/2", 2"
1
75-0168
1b
Piston 2
1
/2"
1
75-0169
1c
Piston 3"
1
75-0159
1d
Piston 4"
1
75-0278
2a
Piston Seal 1
1
/2", 2"
1
75-0292
2b
Piston Seal 2
1
/2", 3"
1
75-0293
2c
Piston Seal 4"
1
75-0236
3a
Adapter Gasket 1
1
/2", 2"
1
75-0113
3b
Adapter Gasket 2
1
/2", 3"
1
75-0093
3c
Adapter Gasket 4"
1
75-0233
23a
Flange Gasket 1
1
/2", 2"
2
75-0138
23b
Flange Gasket 2
1
/2"
2
75-0125
23c
Flange Gasket 3"
2
75-0137
23d
Flange Gasket 4"
2
75-0253
V-Port/Seat Kit 1½"
75-1029
V-Port/Seat Kit 2"
75-1030
V-Port/Seat Kit 2½"
75-1031
V-Port/Seat Kit 3"
75-1032
V-Port/Seat Kit 4"
75-1033
Above kits consist of:
4a
V-Port/Seat 1
1
/2"
1
75-0369
4b
V-Port/Seat 2"
1
75-0177
4c
V-Port/Seat 2
1
/2"
1
75-0178
4d
V-Port/Seat 3"
1
75-0179
4e
V-Port/Seat 4"
1
75-0313
3a
Adapter Gasket 1
1
/2", 2"
1
75-0113
3b
Adapter Gasket 2
1
/2", 3"
1
75-0093
3c
Adapter Gasket 4"
1
75-0233
6a
Seat Seal O-ring 1
1
/2", 2"
1
75-0274
6b
Seat Seal O-ring 2
1
/2"
1
75-0275
6c
Seat Seal O-ring 3", 4"
1
75-0276
7
Seat Screw
1
75-0220
8a
Closing Spring 1
1
/2", 2"
1
75-0171
8b
Closing Spring 2
1
/2"
1
75-0201
8c
Closing Spring 3"
1
75-0248
8d
Closing Spring 4"
1
75-0235
5a
Seat Ring 1
1
/2", 2"
1
75-0084
5b
Seat Ring 2
1
/2"
1
75-0170
5c
Seat Ring 3"
1
75-0071
5d
Seat Ring 4"
1
75-0231
16a
Manual-Opening Stem
1
1
/2" through 3"
1
75-0079
16b
Manual-Opening Stem 4"
1
75-0427
17a
Seal Cap 1
1
/2" through 3"
1
75-0139
17b
Seal Cap 4"
1
50-0260
ITEM
DESCRIPTION
QTY
PART NO
Gasket Kit 1½", 2"
75-1039
Gasket Kit 2½"
75-1040
Gasket Kit 3"
75-1041
Gasket Kit 4"
75-1042
Above kits consist of:
3a
Adapter Gasket 1
1
/2", 2"
1
75-0113
3b
Adapter Gasket 2
1
/2", 3"
1
75-0093
3c
Adapter Gasket 4"
1
75-0233
6a
Seat Seal O-ring 1
1
/2", 2"
1
75-0274
6b
Seat Seal O-ring 2
1
/2"
1
75-0275
6c
Seat Seal O-ring 3", 4"
1
75-0276
9a
Back-Up Washer 1
1
/2" through 3"
1
75-0245
9b
Back-Up Washer 4"
1
50-0351
10a
Stem O-ring 1
1
/2" through 3"
1
50-0179
10b
Stem O-ring 4"
1
50-0253
11a
Stem Washer 1
1
/2" through 3"
1
50-0046
11b
Stem Washer 4"
1
50-0247
12a
Stem Packing 1
1
/2" through 3"
1
50-0045
12b
Stem Packing 4"
1
50-0248
13a
Packing Nut 1
1
/2" through 3"
1
50-0013
13b
Packing Nut 4"
1
50-0251
14a
Seal Cap O-ring
1
50-0432
14b
Seal Cap Gasket
1
50-0270
15a
Stem Pin 1
1
/2" through 3"
1
75-0173
15b
Stem Pin 4"
1
75-0434
23a
Flange Gasket 1
1
/2", 2"
2
75-0138
23b
Flange Gasket 2
1
/2"
2
75-0125
23c
Flange Gasket 3"
2
75-0137
23d
Flange Gasket 4"
2
75-0253
Solenoid Tube Gasket
1
70-0301
Port O-ring and Gasket
3
75-1071
18a
Adapter, 1 Port 1
1
/2", 2"
1
75-0060
18b
Adapter, 3 Port 1
1
/2", 2"
1
75-0384
18c
Adapter, 1 Port 2
1
/2", 3"
1
75-0056
18d
Adapter, 3 Port 2
1
/2", 3"
1
75-0493
18e
Adapter, 1 Port 4"
1
75-0334
18f
Adapter, 3 Port 4"
1
75-0801
19
Gauge Port Plug (
1
/4" NPT)
1
75-0189
20a
Adapter Bolts 1
1
/2", 2"
4
75-0175
20b
Adapter Bolts 2
1
/2", 3"
4
65-0057
20c
Adapter Bolts 4"
4
75-0291
21a
Body 1
1
/2", 2"
1
75-0016
21b
Body 2
1
/2"
1
75-0018
21c
Body 3"
1
75-0019
21d
Body 4"
1
75-0215
22
Flange (Various)
2
FACTORY
24a
Flange Bolt 1
1
/2", 2"
8
70-0135
24b
Flange Bolt 2
1
/2", 3"
8
75-0202
24c
Flange Bolt 4"
8
75-0279
25a
Flange Nut 1
1
/2", 2" (
5
/8"-11)
8
70-0136
25b
Flange Nut 2
1
/2", 3" (
3
/4"-10)
8
75-0210
25c
Flange Nut 4" (
7
/8"-9)
8
75-0280
R429d
16
MAR 2002
